MiBoxer COB RGB+CCT strip light 24V IP20

Product Name: LED Special Adapter (24VDC / 3A)

Model No.: P072-24-A

Input Voltage: 100-240V~   50/60Hz

Input Current: 1.5A Max.

Power Consumption (no loading): <0.21W

Output Voltage: 24V⎓

Output Current: 0 - 3A

Power: 72W Max.

Efficiency: 90% (120V~ at full load) / 92% (230V~ at full load)

Working Temperature: 0~40℃

Storage Temperature: -20~80℃

Working Humidity: 10~90%RH non-condensing

Product Name: 75W RGB+CCT Dimming LED Driver (WiFi+2.4G)

Model No.: WL5-P75V24

Working Voltage: AC100V~240V  50/60Hz

Output Voltage: DC24V

Output Current: Max 3A

WiFi Standard: IEEE 802.11b/g/n 2.4GHz

Bluetooth Protocol: Bluetooth 4.2 (low power consumption)

RF: 2.4GHz

Remote Control Distance: 30m

Ta:40℃     Tc:85℃

• Built-in power adapter

• Support “Tuya Smart” app control

• Support music rhythm

• Support third-party voice control (Alexa, Google Assistant)

• 2.4G RF Remote controllable

• 16 Million colours to choose

• Brightness and colour temperature adjustable

Product Name: RGB+CCT LED Controller (Zigbee 3.0)

Model No.: FUT039Z

Working Voltage: DC12~24V

Output: 6A/Channel

Total Output: Max 12A

Wireless Technology: Zigbee 802.15.4

Zigbee Wireless Frequency: 2.400-2.480GHz

Control Distance: 100m (open area)

Working Temperature: -10~40℃

Product Name: RGB+CCT LED Controller (WiFi+2.4G)

Model No.: FUT039W

Working Voltage: DC12~24V

Output: 6A/Channel

Total Output: Max 12A

WiFi Standard: IEEE 802.11b/g/n 2.4GHz

Bluetooth Protocol: Bluetooth 4.2 (low power consumption)

RF: 2.4GHz

Remote Control Distance: 30m

Working Temperature: -10~40℃

• Support “Tuya Smart” app control

• Support music rhythm

• Support third-party voice control (Alexa, Google Assistant)

• 2.4G RF Remote controllable

• 16 Million colours to choose

• Colour temperature adjustable

• Brightness and saturation controllable

Product Name: 2.4GHz RGB+CCT LED Controller

Model No.: FUT039S

Working Voltage: DC12V~24V

Working Temperature: -10~40°C

Output Max: 6A/Channel

Total Output Max:12A

RF: 2.4GHz

Control Distance: 30m

Output connection: Common anode

• 2.4G RF wireless transmission technology

• 16 Million colours to choose

• Colour temperature adjustable

• Brightness and saturation controllable

• Control distance: 30m

Product Name: 12W RGB+CCT LED Square Wall Light (Zigbee 3.0 + 2.4G)

Model No.: WA5-12S-ZR

Input Voltage: AC100-240V

Power: 12W

PF: >0.5

CRI: >80

Colour Temperature: 2700K~6500K

Luminous Flux: 1000LM

Luminous Efficiency: 85LM/W

Communication Protocol: Zigbee 3.0 + 2.4GHz

Control Distance: Zigbee: 50m (open area), 2.4G RF Remote: 30m

IP Rate: IP66

Working Temperature: -20~45°C

Wireless Technology: Zigbee 802.15.4

Zigbee Wireless Frequency: 2.400-2.480GHz

Illumination Distance: >8m

• Product follows Zigbee 3.0 standard protocol

• Zigbee control distance: 50m (open area)

• Compatible with Mi-Light/MiBoxer 2.4GHz series remote

• 2.4G RF Remote Control Distance: 30m

• 16 Millions of colours to choose

• Brightness and colour temperature adjustable

• IP66 waterproof

The purpose of the bypass capacitor is to address the issue where the light strip remains faintly lit even after being switched off, a situation typically arising from residual power in the supply.

Product Name: 4-Zone Color Temperature Remote

Model No.: FUT094

Working Voltage: 3V (AAA * 2PCS)

Standby Power Consumption: 20μA

Transmitting Power: 6dBm

RF: 2.4GHz

Control Distance: 30m

Transmission Frequency: 2400-2483.5MHz

Modulation Method: GFSK

Working Temperature: -10~40°C

• 2.4G RF wireless transmission technology

• It can control MiBoxer/Mi-Light 2.4G series products

• Control distance: 30m

• Colour temperature and Brightness adjustable
