MiBoxer 9W RGB+CCT LED garden light (Zigbee 3.0) FUTC02Z

Product Name:  RGB+CCT Remote (Zigbee 3.0)

Model No.: FUT089Z

Working Voltage: 3V (AAA * 2PCS)

Transmitting Power: 10dBm

Standby Power Consumption: 20μA

Max Controllable Lights: 25 Pcs

Control Distance: 100m (open area)

Working Temperature: -10~40°C

• Supports up to 7 zones

• Adopt Zigbee 3.0 standard protocol

• Control distance: 100m (open area)

• It can control ON/OFF, RGB colour, colour temperature, saturation and brightness for Zigbee 3.0 lights

Product Name: 6W RGB+CCT LED Garden Light (Zigbee 3.0)

Model No.: FUTC04Z

Voltage: 100-240V~   50/60Hz

Power: 6W

PF: >0.5

Work Temperature: -20~45°C

Colour Temperature: 2700K~6500K

CRI: >80

Luminous Flux: 550LM

Luminous Efficiency: 90LM/W

Lifespan: 50000 hours

Beam Angle: 25°

Illumination Distance: >10m

IP Rate: IP66

Wireless Technology: Zigbee 802.15.4

Zigbee Wireless Frequency: 2.400-2.480GHz

Control Distance: 100m (open area)

Product Name: I Type 3 Pin Connector

Model No.: AM-GP-20NI3N

Wire Diameter: 3mm-12mm

Material: Nylon

IP Rate: IP68

Application: Outdoor lights

Size: Φ24.2*79mm

Product Name: T Type 3-Pin Connector

Model No.: AM-GP-20NT3N

Wire Diameter: 3mm-12mm

Material: Nylon

IP Rating: IP68

Application: Outdoor lights

Size: 102*66*25mm

Product Name: X Type 3 Pin Connector

Model No.: AM-GP-20NX3N

Wire Diameter: 3mm-12mm

Material: Nylon

IP Rate: IP68

Application: Outdoor lights

Size: 102*102*25mm

Product Name: Zigbee 3.0 Wired Gateway

Model No.: ZB-Box2

Input: DC5V / 1A (Micro USB)

Working Temperature: -10~40°C

Wireless Technology: Zigbee 802.15.4

Zigbee Wireless Frequency: 2.400-2.480GHz

ZigBee Transmitting Power:10dBm

Max Connected Device: 128

Zigbee Control Distance: 100m (open area)

Product Name: Zigbee 3.0 Wireless Gateway

Model No.: ZB-Box1

Input: DC5V/1A (Micro USB)

Working Temperature: -10~40°C

Wireless Technology: WiFi 802.11 b/g/n (Zigbee 802.15.4)

WiFi Wireless Frequency: 2.400-2.4835GHz

Zigbee Wireless Frequency: 2.400-2.480GHz

Transmitting Power: WiFi 20dBm / ZigBee 10dBm

Max Connected Device: 50

Zigbee Control Distance: 100m (open area)
