Light colour: RGB (multicolour)
Voltage: 12V DC
Colour temperature of the light: N/A
Luminous flux: 180lm/m
Power (meter): 7,2W
LED type: SMD5050
Amount of LEDs: 30 LEDs/m
Lighting angle: 120°
Cutting section: 5cm
The degree of protection: IP20
Sold per: pack (5m)
Prestige DIGITAL WS2811 magic LED strip light 150 SMD IP20
DIGITAL TAPE Epistar LED MAGIC STRIP RGB is an absolute novelty on the LED lighting market.
The MAGIC RGB digital TAPE differs from the classic RGB LED TAPE with the possibility of achieving a virtually infinite number of light illumination effects.
While with the classic RGB LED strip, all 5050 LEDs work in parallel, DIGITAL TAPES IN COMBINATION WITH THE CORRECT MAGIC RGB CONTROLLER gives the user a series of unprecedented possibilities of lighting effects - each segment (3 LEDs) works independently, making it possible to create light animations.
Advantages of the MAGIC STRIP Digital Tape:
Each section on the MAGIC Digital Tape works independently, making it possible to create light animations,
It has a built-in most popular Chip WS 2811, thanks to which it works with all controllers for Digital tapes from our offer,
The tape has a factory EASY LED input matching the MINI Digital RGB Controller
Allows you to obtain any static colour for the traditional backlight in RGB colours,
30 Powerful LEDs on the subway are perfect for emphasizing the illuminated surface and for decorative purposes,
The maximum configuration consumes only 7.2W from one meter,
Disadvantages of the MAGIC Strip Digital Tape:
The degree of protection IP20 - internal use
Should there be a need to choose a tape with an increased degree of protection (eg for a bathroom, gazebo or terrace), we invite you to familiarize yourself with water-resistant Digital tapes.
RGB LED strip with 5050 type 3in1 LEDs gives light much brighter than standard 3528 diodes - LEDs used in this technology have 3 light spots in each diode (R-red, G-green, B-blue). Thanks to this, the 5050 LED strip shines even three times brighter compared to the commonly encountered LED strip with regular 3528 diodes.
Application:
Ceiling lighting
Furniture lighting
Lighting cavities
Lighting of stairs
Mirror lighting
Shelves lighting
Interior lighting
Vehicle lighting
and many others
Prestige DIGITAL WS2811 magic LED strip light 150 SMD IP20 specification
Type: | magic LED strip |
LED type: | 5050 SMD (EPISTAR) |
Lamp life in hours: | 50,000h |
Colour: | RGB |
Energy class: | A+ |
Ignition time: | <0,2s |
Steering chip: | WS2811 |
Voltage: | 12V |
Dimensions [mm]: | H3 x L5000 x W10 |
Power consumption: | 7,2W/M |
Beam angle: | 120° |
The number of cycles On/Off. | 20,000 |
IP rating: | IP20 (non-waterproof) |
Lamp power factor: | 0,5 |
The density of diodes: | 30/M |
Brightness: | 900lm |
Colour rendering [CRI]: | Ra>80 |
Warranty: | 2 years |
Prestige DIGITAL WS2811 magic LED strip light 150 SMD IP20 package includes
1 x 5m LED strip on a roll in a retail packaging
Data sheet
- Rated Power
- 36W
- Light Colour
- RGB
- Rated Voltage
- 12V
- Luminous Flux
- 900lm
- CRI
- Ra≥80
- Beam Angle
- 120°
- Power Factor
- ≥0.5
- Features
- Dimmable
- Lifespan
- 50,000h
- Warranty
- 2 years
- Light Source
- LED
- Pack Quantity
- 5m
- Packaging
- Original retail colour packaging
- Country/Region Of Manufacture
- China
- Type Of Material
- PCB
- Design
- Tape
- Current Type
- DC
- Power Source
- 12V DC
- Class
- LED strip light
- Unit Type
- Meter
- Size
- 5m
- Output Voltage
- 12V
- LED Chip Code
- 5050
- LED String/Strip Type
- WS2811 30 SMD 5050
- Occasion
- Multipurpose
- Style
- Novelty
- Item Length
- 5000mm
Specific References
- EAN13
- 5902026435734
- MPN
- P0884
