LED line® strip 70 SMD6060 12V 6000-7000K 160° wide beam IP20

Light colour: cold white

Voltage: 12V DC

Colour temperature of the light: 6000-7000K

Luminous flux: 1260lm/m

Power (meter): 18W

LED type: SMD6060

Amount of LEDs: 14 LEDs/m

Lighting angle: 160°

Cutting section: 7cm

The degree of protection: IP20

Sold per: pack (5m)

Read moreShow less
Limited special offer
£24.96 (VAT incl.) £31.20
-20%
(£4.99 per metre)
Last items in stock 2 Items
Close
1 Review
Condition
New
Reference:
P2098
Brand:
Love1
Add to wishlist
Add to compare0
Description

Wide beam LED strip 70 SMD6060 12V 6000-7000K 160° IP20

A unique LED strip with an optical system for the advertising industry. It combines easy and quick installation of LED strips with a wide beam angle of 160°, previously available only in LED modules. Its quick and easy installation makes the tape also ideal for highlighting stretch ceilings.

LED line wide beam strip for advertising

The WIDE BEAM SMD6060 LED strip has been designed for specialist lighting applications. The LED strip colour temperature is 6000-7000 Kelvins. The 5m roll is a standard pack of this LED strip. The LED chips used in the built of this LED strip are SMD6060. The current consumption of 1.5A and the luminous efficacy of 70 lm/W. The power consumption is 18W per metre. The luminous flux of 1m section of the LED strip is 1260lm. The constant voltage of 12V DC powers up this LED strip. The LED's beam angle is 160°. There are 14 LED chips on each 1m section of the LED strip. The amount of copper (expressed in ounces) used for this item's PCB is 2.

wide beam LED strip can save up even more on electricity bills

The PWM dimmers are the compatible dimmer types. The ingress protection rating for this item is IP20. The Ra colour rendering index is 80. The cutting section is 7cm. Type of adhesive tape - 3M 300 LSE guarantees easy and the strongest adhesion to the substrate. The lifespan of every single diode which this item is equipped with is over 100000. The Energy class is A. Ambient temperature suitable for operation -20/+45 °C.

Product designed for indoor use only.

LED line® strip 70 SMD6060 12V 6000-7000K 160° wide beam IP20 specification

Colour temperature 6000-7000K
Colour of the light White
Luminous flux (1m) 1260lm
Wattage (1m) 18W
Luminous efficacy 70lm/W
Current (1m) 1.5
Colour Rendering Index Ra 80
Metres per roll 5
Energy class A
Lamp's warm-up time to 60% 1
Lumen maintenance factor (LLMF) >0.7
Product weight with packaging 95g
Full box quantity 75pc
Master carton weight 8,93kg
Laminate (colour) White
Height 4mm
Warranty  5 years
Width 10mm
Read moreShow less
Product Details
P2098

Data sheet

Cutting Section
70mm
Rated Power
18W/m
Light Colour
Cold white
Rated Voltage
12V
Luminous Flux
1260lm/m
CRI
Ra≥80
Beam Angle
160°
Features
Dimmable
Lifespan
100.000h
Ingress Protection
IP20
Model Number
244056
Certification
CE
RoHS
Warranty
5 years
Light Source
LED
Operating Temperature
-20°C~+40°C
ON/OFF Cycles
≥50000
Pack Quantity
5m
Packaging
Original retail colour packaging
Country/Region Of Manufacture
China
Type Of Material
PCB
Colour
White
Design
Tape
Current Type
DC
Power Source
12V DC
Colour Changing
No
Class
LED strip light
Colour Temperature
6500K
Energy Efficiency Rating (A-G)
E
Unit Type
Meter
Size
5m
Output Voltage
12V
LED Chip Code
6060
LED Strip Width
10mm
Installation Area
Indoor
Item Length
5000mm
Item Width
10mm
Item Weight
0.095kg
Item Height
4mm
Wholesale Box Quantity
75 rolls

Specific References

EAN13
5901583244056
MPN
P2098
Shipping Info
Wholesale shipping
