DIY Guide: Installing LED line® EasyFix Round Panel Downlights

Why Choose LED line® EasyFix Panels?

The LED line® EasyFix round panel downlights are a perfect blend of simplicity and performance. Available in 6W, 12W, 18W, and 24W variants, these panels offer both surface and recessed mounting options, making them ideal for a variety of room types.

• Versatile mounting: surface or recessed
• UV-resistant housing keeps the white finish pristine
• High quality light: 2700K (warm white) or 4000K (neutral); CRI ≥ 80; 120° beam angle
• Flicker-free lighting is easy on the eyes and promotes comfort
• Long lifespan: approximately 30,000 hours

Tools You’ll Need

• Stud finder (if recessed mounting)
• Drill with appropriate drill bits
• Wire stripper
• Screwdriver
• Insulated voltage tester
• Measuring tape and pencil
• Ladder

Installation in 6 Simple Steps

1. Switch off the power at your consumer unit before starting any work.
2. Mark the position where you'd like to mount the panel, ensuring spacing aligns with room layout and illumination needs.
3. Cut the hole (for recessed):
   • 6W panel → hole diameter 55-90 mm
   • 12W → 60-135 mm
   • 18W → 60-185 mm
   • 24W → 60-260 mm
4. Connect the wires:
   • Use the built-in driver
   • Attach live (brown), neutral (blue), and earth (green/yellow), if applicable
   • Ensure all joints are secure with a terminal connector
5. Mount the panel:
   • For recessed: insert spring clips
   • For surface: use the supplied adjustable rails
6. Turn the power back on and test the light for correct operation and stability.

Tips for a Professional Finish

Make sure you:

• Double-check that wiring is turned off before starting work
• Use properly rated connectors and cable-rated for ceiling installation
• Respect IP ratings—these panels are IP20 (indoor use only)
• Space multiple panels evenly to ensure consistent lighting without dark spots
