Mi-Light LED floodlight FUTT03
The RGB+CCT 30W LED floodlight is a multicolour LED floodlight with the ability to change the colour temperature with the Mi-Light (radio remote control, wall panel or Wi-Fi module). LED floodlights are based on SMD LEDs emitting the light output of 2500-2800lm. This illuminator will perfectly suit the outdoor lighting of a variety of architectural objects, parks or public spaces, giving a decorative accent of illuminated space. Works with Mi-Light series controllers.
The remote control or wall panel need to be purchased separately. For compatible devices please see Table #1.
Features of LED floodlight FUTT03:
Housing made of aluminium alloy
Get any colour from the RGB palette
Monochrome colour - warm and cold available at any time
The radio range is 30 meters
Alternative Wi-Fi control
Transmission of the received radio signal
Automatic synchronization between devices
A small amount of energy in the form of heat
High light efficiency
Low power consumption
Long life of LEDs
Communications of the Mi-Light series are characterized by wireless communication via radio via a remote control device or a wall panel. The range of this connection is 30 meters in the open area, provided that it is not exposed to various types of interference. Products that work with the FUTT03 receiver are listed in the following table 1 or in the "related products" category.
To access the control over the Wi-Fi network you need to purchase the appropriate module, which you will find in the "Related Products" tab.
Table 1. Co-operating devices with LED illuminator - Mi-Light - FUTT03
||Mi-Light 8-zone RGB+CCT remote controller FUT089
||Mi-Light 8-zone smart panel remote controller B8
||Mi-Light 2.4GHz 4-zone RGB+CCT remote controller FUT092
||Mi-Light WiFi iBox smart light iBox1
||Mi-Light WiFi controller iBox2
Auto synchronization and retransmission - precision in operation
When more than one receiver is controlled by one transmitter, the installation is synchronized at the same time without any delay in operation. Increasing the radio signal in the installation is possible with the use of several receivers. These devices are characterized by the transmission of the received signal to the next device, thereby increasing the range of control of the LED installation (distance between receivers cannot be more than 30m).
Full control - cooperation with broadcasting equipment
The wireless radio through which the device communicates provides a full palette of control possibilities. Depending on the product, control can be carried out with the help of many available 2.4GHz radio transmitters. This basic form of communication provides stable LED lighting control within 30 meters of the open area. In addition, most of the products can be expanded to include an alternative form of control through the use of a Wi-Fi module that enables the integration of our mobile application with a compatible Mi-Light device. The transmitters that work with your device can be seen above in the table or product specifications.
Robust housing - high-temperature discharge
The floodlights of this series are characterized by high durability and effective heat dissipation through the use of the material from which they were made. The aluminium ribs on the back of the LED illuminator also function as a heat sink, making the LEDs highly durable. The rear handle on the unit allows stable and secure mounting of the LED illumination.
High air tightness - ideal for outdoor applications
The outdoor decorative arrangement of objects using the Mi-Light floodlights is possible through the use of hermetic enclosure of the device. The construction of the device makes it possible to work in difficult weather conditions that do not expose the unit to permanent damage. The Mi-Light floodlight is rated at IP65.
Specification of Mi-Light LED floodlight FUTT03:
||86-265V AC 50/60Hz
|The power of the white diode
|The power of the RGB diode
|Rated luminous flux
|The colour temperature of the light
|Power consumption at rest
|Colour rendering index
|The possibility of obtaining a colour
|Lamp power factor
|Nominal radiation angle
||via radio (wirelessly)
||see "Related products" or "Table No. 1"
|Source of light
|Degree of protection IP
||200mm (226,5mm) x 167mm x 40mm
Mi-Light 30W RGB+CCT LED floodlight FUTT03 package contains:
1 x RGB+CCT outdoor light in a retail packaging
1 x User manuals
