Mi-Light 2.4GHz 4-zone RGB+CCT remote controller FUT092
  • Mi-Light 2.4GHz 4-zone RGB+CCT remote controller FUT092
  • Mi-Light 2.4GHz 4-zone RGB+CCT remote controller FUT092 - back
  • Mi-Light 2.4GHz 4-zone RGB+CCT remote controller FUT092 - size

Mi-Light 2.4GHz 4-zone RGB+CCT remote controller FUT092

£14.40
VAT included

Product Name: 2.4GHz 4 Zone RGB+CCT Remote Controller

Model No.: FUT092

Voltage: 3V (section 2 batteries)

Transmission Frequency: 2.4GHz

Modulation Method: GFSK

Transmitting Power: 6dBm

Standby Power Consumption: 20uA

Control Distance: 30m

Size: 138*56*38mm

Must-have accessories
Quantity
Delivery within 4-6 working days

Mi-Light 2.4GHz 4 zone RGB+CCT remote controller FUT092

Mi-Light 2.4GHz 4-zone RGB+CCT remote controller FUT092 technical picture size dimensions

16 million colours adjustable colour saturation colour temperature wireless transmission MiLight Mi.Light Mi-Light

Innovative 4-zone LED radio remote control in the Mi-Light series, which allows individual control of each zone using the radio receiver. Characterised by full control of both the colour of the RGB colour palette as well as the active change of brightness and colour temperature CCT. This transmitter is compatible with the Mi-Light series (receivers, bulbs, downlights, etc.).

unique design transparent crystal face cover fasionable and beautiful design of the remote controller for smart lighting

Receiver (s) must be purchased separately. Compatible receivers - (see Table 1).
Application for installation:
RGB+CCT - multicolour with variable colour temperature

RGB+CCT remote controller full touch 4-zone group control

Key features of the Mi-Light 2.4GHz 4 zone RGB+CCT remote controller FUT092
Dimming and brightening of the connected LED lighting
An active colour change from RGB colour palette
Possibility to turn white (using RGB+W strip)
Colour temperature CCT (warm and cold colour)
Control of each zone separately
Enables/disables all zones simultaneously
Active dynamic programs to use (change mode/speed)

with the luminous material on the edge you can easly find it at night remote controller for smart lighting

Features of the Mi-Light 2.4GHz 4 zone RGB+CCT remote controller FUT092
Supports up to 4 zones
Application for RGBW+CCT strips
Radio communication with receivers (2.4GHz)
Works with Wi-Fi controller (optional)
Built-in dynamic programs that enrich RGB installations
Ability to extend the installation at any time
Ability to ignite blends of monochrome diodes in RGB colour mode
Touch buttons
24 months warranty
elegant and smooth surface good feel in touch remote controller LED lights control

The basic way of communicating receivers with the FUT092 transmitter is by radio, it is through which data transmission takes place, giving us the freedom to use the wireless LED driver. Optional Wi-Fi control, which lets you control your lighting with your mobile device, is available only through the appropriate Wi-Fi module.

2 x AAA battery remote controller power supply





Table 1. Compatible devices with Mi-Light 2.4GHz 4 zone RGB+CCT remote controller FUT092

Product codeProduct name
FUT105 Mi-Light 12W RGB+CCT LED light bulb FUT105
FUT012 Mi-Light 9W RGB+CCT LED light bulb FUT012
FUT018 Mi-Light 5W GU10 RGBW LED spotlight FUT018 warm white
FUT018 Mi-Light 5W GU10 RGBW LED spotlight FUT018 cold white
FUT062 Mi-Light 9W RGB+CCT LED ceiling spotlight FUT062
FUT063 Mi-Light 6W RGB+CCT waterproof LED downlight FUT063
FUT064 Mi-Light 9W RGB+CCT square LED downlight FUT064
FUT066 Mi-Light 12W RGB+CCT LED downlight FUT066
FUT067 Mi-Light 15W RGB+CCT LED downlight FUT067
FUT068 Mi-Light 6W RGB+CCT LED downlight FUT068
FUT069 Mi-Light IP54 waterproof 15W RGB+CCT LED downlight FUT069
FUT043 Mi-Light RGB LED strip controller FUT043
FUT044 Mi-Light RGBW LED strip controller FUT044
FUT045 Mi-Light RGB+CCT LED strip controller FUT045
FUTT07 Mi-Light 100W RGB+CCT LED floodlight FUTT07
FUTT06 Mi-Light 10W RGB+CCT LED floodlight 24V DC FUTT06
FUTT05 Mi-Light 10W RGB+CCT LED floodlight FUTT05
FUTT04 Mi-Light 20W RGB+CCT LED floodlight FUTT04
FUTT03 Mi-Light 30W RGB+CCT LED floodlight FUTT03
FUTT02 Mi-Light 50W RGB+CCT LED floodlight FUTT02
FUTC01 Mi-Light 9W RGB+CCT LED garden light FUTC01
FUTC02 Mi-Light 9W RGB+CCT LED garden light FUTC02
FUTC03 Mi-Light 15W RGB+CCT LED garden light FUTC03
LS2 Mi-Light 5 in 1 smart LED strip controller LS2
FUT037 Mi-Light 2.4GHz 4-zone RGB LED strip controller FUT037
FUT038 Mi-Light 2.4GHz 4-zone RGBW LED strip controller FUT038
FUT039 Mi-Light 2.4GHz RGB+CCT strip controller FUT039
FUT013 Mi-Light 5W E14 RGB+CCT LED light bulb FUT013
FUT103 Mi-Light 4W GU10 RGB+CCT LED spotlight FUT103
FUT104 Mi-Light 4W MR16 RGB+CCT LED spotlight FUT104
FUT014 Mi-Light 6W RGB+CCT LED light bulb FUT014
YL5 Mi-Light 5 in 1 WiFi LED controller YL5
YL1 Mi-Light touch RGB WiFi LED controller YL1



Table 2. Dynamic programs for the Mi-Light 2.4GHz 4 zone RGB+CCT remote controller FUT092

NumberFunctionChange speedChange brightness
 1 Pulsating dimming/brightening of red  Possible  Possible
 2 Smooth change of colours available from colour palette (RGB)  Possible  Possible
 3 Liquid temperature change on white diodes (CW/WW)  Possible  Possible
 4 Smooth change of brightness level of RGB+CW/WW LEDs (each is lit separately)  Possible  Possible
 5 Dynamic colour change (red> green> blue> yellow)  Possible  Possible
 6 An energetic and random variation of the colour palette  Possible  Possible
 7 Smooth dimming of red, which ends with three flashes  Possible  Possible
 8 Fluid dimming green, which ends with three flashes  Possible  Possible
 9 Smooth blue dimming, which ends with three flashes  Possible  Possible

Endless possibilities - great functionality

Full colour range change RGB saturation colour temperature dimming functions remote controller for LED lights

The rapidly evolving technology in the LED industry allows for incredible control and innovative solutions available at any time within the reach of our hands. Devices labelled RGBWW or RGB+CCT allow you to obtain each colour from the RGB palette with colour temperature CCT monochrome LEDs, both warm white and cold white. This solution allows the device to be adapted to the conditions of the room, making the product more practical. This feature is incredibly enjoyable, thanks to the well-designed LED drivers that allow you to wirelessly control your LED installation.

Great comfort - 16 million colours to drive
The construction of the Mi-Light series allows full access to the colour palette of up to 16 million colours. Obtaining a given shade of colour depends on the precision of the control, which is usually done with tactile transmitters. The colours of the device are colourful and pleasant, and the effective colour rendering ratio allows you to fully enjoy the colourful mood of the room together with the Mi-Light series products.

Remote construction - control has not been so easy

functions of the RGB+CCT LED smart lighting remote control high-quality product FUT092

Depending on the model of the transmitting device, which mainly occurs as a radio link to the receiver, various control functions can be obtained. The centre of the touchscreen, the main function of the control, it is through it that we can change the colour or the brightness of the LED. At the very top of the remote control, there are buttons to enable/disable all available zones in our LED installation. Buttons for turning on/off the zone are located at the bottom of the device stacked side by side.

Entire room within reach of the hand - zone control
2.4GHz wireless transmission group control remote controller for LED bulbs in your home

Some of the Mi-Light transmitters provide access to multiple zones fully controlled by one device. The use of such a method makes it easy to use the LED installation in a given room, allowing for future expansion of lighting at any time, when we do not need several zones in our installation, just another pairing of the connected receiver together with LED lighting with our device to the next zone. An interesting feature is the ability to program an unlimited number of receivers to a particular zone, in this case only the output parameters of the receiver.

retail box RGB+CCT LED smart remot controller smooth beautiful design

Mi-Light 2.4GHz 4 zone RGB+CCT remote controller FUT092 specification

Application for RGB+CCT installation
Number of zones/channels supported 4
Controlling via Radio
Controlling method Buttons + colour wheel
Powered by 2 x 1.5V AAA battery
Signal modulation GFSK
Type of transmission One-way
Power consumption 6dBm
Standby power consumption 20uA
Compatible with Mi-Light RGB+CCT series (see table #1 for compatibility)
Method of communication 2.4GHz radio
Controlling range up to 30 meters in open area
Colour White
Degree of protection IP20
Model number FUT092
Dimensions[mm] L138 x W56 x H38
Certification RoHS, CE
Warranty 2 years

Mi-Light 2.4GHz 4-zone RGB+CCT remote controller FUT092 size of retail and wholesale packaging cardboard box

Mi-Light 2.4GHz 4 zone RGB+CCT remote controller FUT092 package includes
1 x Remote controller FUT092 (batteries not included)
1 x User Manual (English)

P0002
2017-11-29

Data sheet

Rated voltage
2 x 1.5V
Features
Wireless
Ingress protection
IP20
Model number
FUT092
Certification
CE, RoHS
Warranty
2 years
Light source
LED
Housing colour
White
MPN
FUT092
Pack quantity
1
Packaging
Original retail colour packaging
Country/Region of manufacture
China
Type of material
Plastic
Power source
Battery
Connected Home Compatibility
N/A
Connected Home Protocol
N/A
Type
LED/RGB Controller
Unit type
Unit

Specific References

New product

Download

Mi-Light FUT092 - user manual

This product adopts world-wide used 2.4GHz frequency, GFSK control method, with the features of low power consumption, long distance transmitting, strong anti-interference and fast communication rate; can control specified Mi-Light smart light with colour, colour temperature, saturation and brightness changing

Download (2.08M)
